Description:
The fuel tanker semi-trailer is used for the oil including diesel, essence, crude oil transportation. The oil transport semi-trailer has several designs for the option including the single tire, bogie suspension, double axles, end discharging, etc. The tanker that we designed for the oil tanker semi-trailer will be different according to the different kinds of oil that the customers will transport and the customer's special requirement. The material that we used for the tanker body including aluminum, carbon steel, stainless steel, etc.
There are some customers who talk with us for the tires because the oil semi tanker semi-trailer needs long distances transportation with different road conditions. So for the oil tanker semi-trailer, we will use is the reinforced 12R22.5 tires. the model of 12.00R20 and 13R22.5 for optional. In order to meet the different transporting conditions, we will choose a different type of tires for our tanker trailers.
Specification:
|
walking system |
Axles |
13-ton axles |
| Axles No. | 3 axles | |
| Tire model | 12R22.5 | |
| Leaf spring No. | 10 pcs | |
| Tire No. | 12 pcs | |
| Breaking pads | 13-ton breaking pads | |
| Suspension | strengthen type | |
|
Trailer chassis |
Landing leg |
28-ton landing leg |
| diesel engine | 4012 | |
| air compressor | 14 CBM air compressor | |
| electric input | 7 phrase | |
| lights | LED lights | |
| discharge pipe | yes | |
| Kingpin | 2.0 or 3.5 inch | |
|
tanker info |
tanker thickness |
3-5 mm |
| tanker plate thickness | 4-6 mm | |
| breath valve | yes | |
| discharge valve | yes | |
| manhole | accordingly |
Shipping solution:
By container. The standard size of the oil transport semi-trailer is able to be transported by a flat rack container.
By breakbulk cargo ships. All size of the oil transport semi-trailer is able to be transported by bulk cargo ships.
By RO-RO ships. All size of the fuel tanker semi-trailer is able to be transported by bulk cargo ships.
