Product Attributes :

axle:13 ton axle
tire :12R22.5
floor plate :3 mm
suspension :10 pcs leaf spring
kingpin :2.0 or 3.5 inch

Product Description

40 ft container transport trailer | 20 ft container trailer | container transport use semi-trailer | container truck trailer

container trailer  (4).jpg



Description:

A 40-foot container transport semi-trailer is widely used in the container transport area. The container trailer will be designed according to the customer's requirements about the main structures. The main beams will be confirmed according to the payload.

20 ft container truck trailer is a very special type of semi-truck trailers. This kind of container trailer is only able to transport the 20 ft containers. Which is a good choice for the narrow roads or the companies who always transport the 20 ft containers with a bigger payload?

All the container transport semi-trailers are able to be used for bulk cargo transporting too. It will be a good choice for bulk cargo transport because of the easy loading and unloading.

The container trailer with multi-usage provides us a better solution on road-transportation. The lower cost and better performance make the container trailer plays an important role in road transportation.



Specification:











walking system

Axles

13-ton axles
Axles No. 3 axles
Tire model 12R22.5
Leaf spring No. 10 pcs
Tire No. 12 pcs
Breaking pads 13-ton breaking pads
Suspension strengthen type











Trailer chassis

Main beam height

500 mm
Main beam thickness 14/8/16 mm
Main beam material Q235 B
Floor plate thickness 3 mm
Floor plate type checked steel
side beams #10
Kingpin 2.0 or 3.5 inch







Tanker or box

-

-
- -
- -
- -
- -



Shipping solution:

  1. By container. 2 sets of standard container trailers are able to charge into one 45 high cube container. If the design with rear cut, 2 sets of container trailers are able to charge into one 40 high cube containers.

  2. By breakbulk cargo ships. The container trailers with all sizes are able to transport by breakbulk cargo ships.

  3. By RO-RO ships. All size of container trailers is able to be transported by bulk cargo ships.
